Conversion of nanoparticle concentration units

Depending on your end use application, you may prefer to know the concentration of  nanoparticles (silica, selenium, titanium) in terms of

  • Parts per Million (PPM)
  • WT%
  • Particles/mL
  • Molar
  • Optical Density (OD).

For illustration purposes we will use our selenium nanoparticles but the same principles apply for other nanoparticle types.

Glantreo quantifies the mass of selenium in end products using ICP-OES analysis. Knowing the total selenium in mg/Litre allows us to start calculating the concentration in other forms.

The conversion of mg/Litre to PPM is 1:1. Therefore 1 mg/Litre is the same as 1 PPM. The conversion of PPM to WT 10,000 PPM to 1 WT%.

Therefore:

10,000 mg/Litre = 10,000 PPM = 1 WT%

Zeta Sizing - SeNP

We need to calculate the particles/ml but before we do this we need some additional information, namely the mass of 1 nanoparticle.

Calculating the mass of 1 nanoparticle

Firstly, we must calculate the volume of a nanoparticle. Our nanoparticles are spherical, so we can use the equation for the volume of a sphere.

V= 4/3 π r3

Radius (r): Nanoparticle size can be elucidated using SEM or zeta sizing. To calculate the mass of 1 nanoparticle, multiply the calculated volume of 1 nanoparticle by the material density of the element.

TiO2 Particle

Worked Example:

The material density of selenium is 4.32 g/cm3

For a Selenium Nanoparticle of 350 nm diameter, its volume is calculated as (4/3 * π * 175 nm3)

Volume = 2.24 x 107 nm3

This needs to be converted to cm3 by dividing by 1e+21, then multiplied by the material density.

Nm3 to cm3:  2.24E x 107 nm3 ÷ 1 x 1021 nm3/cm3 = 2.24 x 1014 cm3

Multiply by material density: 2.24 x 1014 cm3 x 4.32 g/cm3 = 9.70 x 1014 g

Mass of one 350 nm Selenium nanoparticle is 9.70 x 1014 g

ti02

Calculating particles/mL

To calculated nanoparticles/mL we use:

N = MC / m

MC is the mass concentration of element used in the experiment in g/mL

m is the mass of an individual nanoparticle

If our final concentration of selenium is 4 g in 1 L, this can be converted to g/mL by dividing by 1,000.

MC = 0.004 g/mL

m = 9.70 x 1014 g/particle

Therefore, in our 4 g in 1 Litre solution of 350 nm Selenium nanoparticles, we have: 4.12 x 1010 particles/mL

Express in molar concentration

If we want this same solution concentration expressed in molar (Mols/Litre) we use:

M = N / 6.02214 × 1023

Where N is the number of particles in solution expressed in particles/L.

Firstly, convert the particles/mL to particles/L by multiplying by 1,000.

4.12 x 1010 particles/ mL x 1000 = 4.12 x 1013 particles/Litre

Then divide by Avogadro’s number

4.12 x 1013 particles/Litre ÷ 6.02214 x 1023 particles/mol = 6.85 x 1011 M

Nanoparticle concentrations are usually expressed in picomole for ease of use

To convert M to pM, multiply by 1 x 1012

6.85 x 1011 M x 1 x 1012 = 68.49 pM
